OV5648 CMOS 5MP MIPI Camera Module For Phone Tablet Rolling Shutter

OV5648 CMOS 5MP MIPI Camera Module For Phone Tablet Rolling Shutter

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	Sinoseen
Certification:	RoHS
Model Number:	SNS-ov5648-V1.0

Payment & Shipping Terms:

Minimum Order Quantity:	3
Price:	negotiable
Packaging Details:	Tray+Anti-static bag in carton box
Delivery Time:	2-3weeks
Payment Terms:	T/T
Supply Ability:	500000 pieces/month

Inquiry

Parameter
Related products
Inquiry

Detail Information

Type:	MIPI Camera Module	Sensor:	1/4" Omnivision OV5648
Resolution:	5MP 2592x1944	Dimensions:	Customizable
Lens FOV:	65°	Focus Type:	Fixed Focus
Interface:	MIPI	Feature:	HD
High Light:	Tablet MIPI Camera Module , Rolling Shutter MIPI Camera Module , MIPI OV5648 Camera Module

Product Description

Introducing our OV5648 CMOS 5MP MIPI Rolling Shutter Camera Module, meticulously crafted for seamless integration into phone and tablet applications. With a pixel size of 1.4μm x 1.4μm and effective resolution of 25921944, it ensures exceptional image clarity. The OV5648 sensor, coupled with its rolling shutter technology, delivers smooth and distortion-free imaging, ideal for capturing dynamic scenes. Customize your lens view with optional FOV65° and F/N configurations, adapting to your specific requirements. Operating within a temperature range of 0°C to 60°C, and storage temperature of -20°C to 70°C, its compact dimensions of 538.5mm offer versatility in design. Elevate your device's imaging capabilities with our OV5648 CMOS Camera Module, designed to meet the demands of modern mobile technology.

Specification:MIPI Camera Module

Pixel Size	1.4μm x 1.4μm
Effective Pixels	2592*1944
Image Sensor	1/4"
Sensor Type	OV5648
Lens View	FOV65°(Optional),F/N(Optional)
TV Distortion	<1% (Optional)
Temperature(Operation)	0～60℃
Temperature(Storage)	-20～70℃
Dimension	53*8.5mm (Customizable)
