Full Featured HD OV2735 30FPS USB Camera Module for Driving Recorder Dash Cams
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Sinoseen |
| Certification: | RoHS |
| Model Number: | SNS-WK2735-V1.0 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiable |
| Packaging Details: | Tray+Anti-static bag in carton box |
| Delivery Time: | 2-3weeks |
| Payment Terms: | T/T |
| Supply Ability: | 500000 pieces/month |
- Parameter
- Related products
- Inquiry
Product Description
Sinoseen HD USB Camera Module with the OV2735 sensor delivers 1080p resolution at 30 frames per second, making it ideal for driving recorders and other high-definition applications. Designed for low power consumption, this module operates efficiently within 0°C to 60°C and supports MJPEG and YUV2 video output formats. Key features include programmable settings for gain, exposure, frame rate, and image size, as well as horizontal mirroring, vertical flip, and window cropping. Its versatile design and stable performance make it suitable for various uses including IP cameras and HD analog cameras.
Enhance your driving recorder with the Sinoseen 1080p USB Camera Module, combining high-definition video quality with efficient power use.
|
Module No |
SNS-WK2735-V1.0 |
|
Pixel Size |
3.0μm x 3.0μm |
|
Effective Pixels |
1920(H)X1080(V) |
|
Video output |
YUV2 MJPG |
|
Active Array Size Video Rate |
1080p@30FPS |
|
Image Sensor |
1/2.7" OV2735 |
|
SNR max |
TBDdB |
|
Dynamic range |
TBDdB |
|
OTG |
USB2.0 OTG |
|
AEC |
Support |
|
AEB |
Support |
|
AGC |
Support |
|
Adjustable parameter |
Brightness/Contrast/Color saturation/Hue/Definition/Gamma/White balance/Exposure |
|
Lens view |
FOV:D97° H83°V56°F/N(2.0) |
|
Interface |
USB BUS POWER 5P-1.25mm |
|
Operating Voltage |
DC5V |
|
Operating Current |
MAX120MMA |
|
Operating temperature |
0～60℃ |
|
Storage temperature |
-20～80℃ |
|
Cable length |
Defualt |
|
OS |
WinXP/Vista/Win7/Win8 Linux with UVC(above linux-2.6.26) MAC-OS X 10.4.8 or later Wince with UVC Android 4.0 or above with UVC |
